NGK U2063 / 48290 Ignition Coil Genuine NGK ComponentEssentially the operating principle is the same for all types of ignition coils- whether the classic can-type coil, or in a coil rail system. The device contains two copper wire windings and a laminated iron core. The copper wires are insulated to prevent short circuits. The battery current fed through the primary winding produces a magnetic field whose strength is further increased by the iron core. When this circuit is opened, the magnetic field collapses, inducing a high voltage pulse in the secondary coil.U2 Type Ignition CoilThe number of ignition cables corresponds to the number of spark plugs The NGK ignition coil of the Type U2 is a block ignition coil, which supplies multiple spark plugs with high voltage through ignition cables. Normally, one ignition coil is required per cylinder head.BOX DIMENSIONSHeight (mm): 125Width (mm): 183Length (mm): 165If you are unsure as to whether this is the correct part for your vehicle, please don’t hesitate to contact us. Alternatively please use the cross reference table above.
