The MSTMDP123DP Mini DisplayPort 1.2 to DisplayPort MST hub lets you connect up to three DisplayPort monitors/projectors to a single Mini DisplayPort (1.2) output on your Ultrabook, Laptop, or Desktop computer. Extend Your Display The hub splits a Mini DisplayPort 1.2 output into three separate DisplayPort signals – enabling your computer for high quality multi-monitor applications such as a video wall, extending your desktop, or mirroring your primary display to additional monitors or projectors. Extend Your Performance With separate image outputs and resolution support up to 2560x1600 for two displays, and 1920x1200 for a third display, the DisplayPort MST hub allows monitors connected through the hub to operate individually with the exact same performance as the Mini DisplayPort 1.2 graphics card on your computer. Extend Your Compatibility The MST hub is compatible with Intel® Thunderbolt™, when connected directly to a supporting DisplayPort over Thunderbolt™ I/O port. You can also use DisplayPort video adapters with the MST hub, enabling you to output the additional video signals to HDMI, DVI, or VGA displays. Warranty Information Warranty 2 Years Hardware Converter Type MST Hub Ports 3 Audio Yes Output Signal DisplayPort Connector(s) Connector A 1 - Mini-DisplayPort (20 pin) Male Connector B 3 - DisplayPort (20 pin) Latching Female Performance Maximum Digital Resolutions 2560x1600 Wide Screen Supported Yes Software OS Compatibility Windows 8 (32/64) Windows 7(32/64) Special Notes / Requirements Note DisplayPort 1.2 with MST+HBR2 support from the GPU is required for independent display output Physical Characteristics Color Black Enclosure Type Plastic Product Length 200 mm [7.9 in] Product Width 78 mm [3.1 in] Product Height 20 mm [0.8 in] Product Weight 95 g [3.4 oz] Power Input Voltage 110 ~ 240 AC Input Current 0.5 A Output Voltage 5 DC Output Current 3A Center Tip Polarity Positive Plug Type N Environmental Operating Temperature 0°C to 45°C (32°F to 113°F) Storage Temperature -20°C to 70°C (-4°F to 158°F) Packaging Information Shipping (Package) Weight 0.6 kg [1.3 lb] What’s in the Box Included in Package 1 - 3-Port Multi Monitor Mini DisplayPort to DisplayPort® MST Hub 1 - Power Adapter 1 - Instruction Manual
