Aten VS481B-AT-E Product Key Features • Allows up to four HDMI A/V sources to be connected to one HDMI display. • HDMI (3D, Deep Color, 4kx2k); HDCP 2.2 compatible. • Supports 340MHz bandwidth for ultrahigh 4kx2k video. • Quick and easy switching between HDMI sources via front panel pushbuttons, RS-232 or IR Remote control. • Auto switching modes for auto port selection. • Long distance transmission – up to 15 m (24 AWG). • Consumer Electronics Control (CEC) support. • Supports Dolby True HD and DTS HD Master Audio. • Built-in bi-directional RS-232 serial remote port for high-end system control. • Instant switching between HDMI input sources. • Supports IR extension using a IR extension cable *. • LED indication of video source devices. • Note: The IR extension cable (Part No. 2XRT-0003G) is not included inthis package. Product Overview The VS481B 4-Port HDMI Switch allows you to quickly connect 4 HDMI sources to your HDMI display and easily switch between them via front panel pushbuttons, RS-232 or IR remote control. The front panel’s LEDs indicate the source device selected for the display at a glance. The VS481B supports Ultra HD 4Kx2K, the newest resolution for high definition displays; Auto Switching modes for auto port selection;Instant Switching for a smooth video transition between HDMI ports with increased efficiency; and features a built-in bi-directional RS-232 serial port that allows the switch to be controlled through a high-end controller, PC, and/or home automation/home theater software package. Product Package Contents • 1x VS481B 4-Port HDMI Switch. • 1x HDMI Cable (1.8m/6ft). • 1x IR Remote Control. • 1x Power Adapter. • 1x User Instructions. Product Specification Video Input • Interfaces: 4 x HDMI Type A Female (Black). • Impedance: 100 Î. • Max. Distance: 1.8 m. Video Output • Interfaces: 1 x HDMI Type A Female (Black). • Impedance: 100 Î. • Max. Distance: 15 m. Video • Max. Data Rate: 9 Gbps (3 Gbps Per Lane). • Max. Pixel Clock: 300 MHz. • Compliance: HDMI (3D, Deep Color, 4K), HDCP 2.2 Compatible, Consumer Electronics Control (CEC). • Max. Resolution: Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);, 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4). • Max. Distance: Up to 15 m. Audio • Input: 4 x HDMI Type A Female (Black). • Output: 1 x HDMI Type A Female (Black). Control • RS-232: Connector: 1 x DB-9 Female (Black), Baud Rate and Protocol:, Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No, Flow Control: No. • IR: 1 x Mini Stereo Jack Female (Black). Connectors • Power Connector: 1 x DC Jack, Consumption: 5 VDC, 5W. Power Consumption • DC5V:1.76W:8BTU. Environmental • Operating Temperature: 0 - 50°C. • Storage Temperature: -20 - 60°C. • Humidity: 0 - 80% RH, Non-Condensing. Physical Properties • Housing: Metal. • Weight: 0.48 kg ( 1.06 lb ). • Dimensions (L x W x H): 20.00 x 8.25 x 2.50 cm, (7.87 x 3.25 x 0.98 in.). Carton Lot • 10 pcs. Note • For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
