D-Link DES-1016D 16 Port 10/100 Ethernet Switch The D-Link DES-1016D unmanaged switch with (16) 10/100BASE-T ports is the latest addition to our popular line of Express EtherNetwork products. D-Link’s Express EtherNetwork line of products combines ease of use with unsurpassed performance for an exceptional value. Ease of Use The DES-1016D is truly a Plug-&-Play switch, with features like: Auto Speed Sensing. The Switch senses whether a network device is running at 10Mbps or 100Mbps and automatically adjusts for optimal performance. Auto Negotiation (Full or Half Duplex). Whether you are running at Half- or in Full-Duplex, the Switch automatically negotiates and runs the highest supported transmission rate. Auto MDI/MDIX Crossover. All ports support auto-negotiating MDI/MDIX detection, which eliminates the need for crossover cables or uplink ports. The DES-1016D is the perfect choice for Plug-&-Play support for 10BASE-T and 100BASE-T networks. Wire-speed Performance The DES-1016D features a non-blocking wire-speed architecture, with a 4.8Gbps (in full duplex)switching capacity, for maximum data throughput. The DES-1016D also features an integrated universal power supply, and per port diagnostics LEDs that make it easy to “spot check” for problems. With wire-speed filtering and Store-and-Forward switching, the DES-1016D maximizes network performance while minimizing the propagation of bad network packets. Product Highlights Plug-and-Play High-Speed Switching 4.8Gbits (in full duplex) Non-Blocking Back Plane Up to 200Mbps per Port Wire Speed Reception and Transmission Broadcast Strom Protection Back Pressure Flow Control for Half-Duplex Great for SOHO Environment Number of Built-in Ports 16 x 10/100Mbps port - Auto-negotiation of MDI-II (One MDI-X MIDI uplink port) LEDs Per port : Link, Speed, Duplex, Activity, Collision Performance Transmission Method Store-and-forward Forwarding Rate 14,800 frames/sec max for 10M port 148,000 frames/sec max for 100M port Network latency Less than 80 microseconds for 64-byte frames in store-and-forward mode for 10 Mbps to 100 Mbps transmission Mac Address Automatic MAC Address Learning Address table up to 16K MAC address RAM Buffer Memory : 2Mb RAM buffer dynamically allocated Dimensions 324 x 231 x 45.5 mm (12.75 x 9.0 x 1.79 inches) Manufactures Warranty 5 years Package Contents DES-1016D Switch External UK Power Adapter User’s Guide Quick Installation Guide Please note: networking components such as switches, routers and wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance.
