Key Features • Supports 11th and 10th Gen Intel® Core™ Series Processors • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs • Direct 12+1 Phases Digital VRM Solution with 60A DrMOS • Shielded Memory Routing for Better Memory Overclocking • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks • Onboard Intel® WiFi 6 802.11ax 2T2R & BT5 with AORUS Antenna • AMP-UP Audio with ALC1220 and WIMA Audio Capacitors • Fast 2.5GbE LAN with Bandwidth Management • Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x4 M.2 with Thermal Guards • SuperSpeed USB 3.2 Gen2x2 TYPE-C® delivers up to 20Gb/s transfer speeds • Pre-installed IO Shield for Easy and Quick Installation • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP • Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card DIRECT POWER DESIGN Z590 AORUS ELITE AX motherboard uses an 12+1 phases digital CPU power design which includes both digital PWM Controller and DrMOS. These 100% digital controller and additional 8+4 Solid-pin CPU Power Connectors offer incredible precision in delivering power to the motherboard’s most power-hungry and energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from the new Intel 11th Gen CPU. ADVANCED THERMAL SOLUTION Z590 AORUS ELITE AX uses high performance Full Covered thermal design with high coverage MOSFET Heatsinks and thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers and gamers. NEXT GENERATION CONNECTIVITY A high-end product needs to be future-proof so your system stays up-to-date with the latest technology. Z590 AORUS ELITE AX provides all next generation network, storage, and WIFI connectivity to keep you up to speed. Realtek High-End HD Audio Codec ALC1220 120dB(A) SNR HD Audio with Smart Headphone Amp automatically detects impedance of your head-worn audio device, preventing issues such as low volume and distortion. With the new VB series audio controller, stream your voice to the world vibrantly with both front/rear microphone SNR up to 110/114dB(A).
