Device Type: Network surveillance camera Form Factor: Turret Connectivity Technology: Wired Width: 13.83 cm Depth: 13.83 cm Height: 12.52 cm Weight: 750 g Type: Color - Day&Night - fixed - dust resistant / water resistant Digital Video Format: MJPEG, H.264, H.265, H.265+, H.264+ Max Digital Video Resolution: 2688 x 1520 Motion Detection: Yes Exposure Range: 1/3 sec - 1/100000 sec Minimum Illumination: 0.0005 lux - color - F1.0 - AGC on, 0 lux - IR - infrared LEDs on Video Capture: 2688 x 1520, 50 Hz @ 25 fps, 1920 x 1080, 50 Hz @ 25 fps, 1280 x 720, 50 Hz @ 25 fps, 2688 x 1520, 60 Hz @ 30 fps, 1920 x 1080, 60 Hz @ 30 fps, 1280 x 720, 60 Hz @ 30 fps, 640 x 480, 50 Hz @ 25 fps, 640 x 360, 50 Hz @ 25 fps, 640 x 480, 60 Hz @ 30 fps, 640 x 360, 60 Hz @ 30 fps, 1920 x 1080, 50 Hz @ 10 fps, 1280 x 720, 50 Hz @ 10 fps, 640 x 480, 50 Hz @ 10 fps, 640 x 360, 50 Hz @ 10 fps, 1920 x 1080, 60 Hz @ 10 fps, 1280 x 720, 60 Hz @ 10 fps, 640 x 480, 60 Hz @ 10 fps, 640 x 360, 60 Hz @ 10 fps Features: Manual white balance, Backlight Compensation (BLC), sharpness control, progressive scanning, saturation control, brightness control, contrast control, image mirror, Wide Dynamic Range (WDR), Privacy Mask Function, Highlight Compensation (HLC), Scene Change Detection, NAS-Ready, manual gain control, reset button, password protection, triple video stream, Region of Interest (ROI), Variable Bitrate (VBR), Constant Bitrate (CBR), intrusion detection, 3D Digital Noise Reduction Technology, ONVIF (Profile S) support, ONVIF (Profile G) support, Pixel Counter Support, Line Crossing Detection, heartbeat, anti-flicker, Internet Server Application Programming Interface (ISAPI), DORI coverage, Vehicle Detection, IP address filtering, region exiting detection, region entrance detection, HTTPs encryption, human detection, White Light, environment noise filtering, ONVIF (Profile T) support, up to 6 channels simultaneous live view, Automatic Network Replenishment (ANR), Scalable Video Coding (SVC), Face Capture, smart supplement light, Hikvision ColorVu technology, 24/7 color imaging, 2m identify distance, 23m observe distance, 11m recognize distance, 58m detection distance Type: 4 MP CMOS 1/1.8" Type: M16 mount - fixed focal Focal Length: 2.8 mm Lens Iris: F/1.0 fixed iris Horizontal Field of View (degree): 112 Vertical Field of View (degree): 61 Diagonal Field of View (degree): 134 Range (degree): 0 to 360 Range (degree): 0 to 75 Network Interface: Ethernet 10Base-T/100Base-TX Network Protocols: DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, ICMP, SNMP, RTSP, RTP, HTTPS, UPnP, IPv6, Bonjour, RTCP, PPPoE, SMB, IGMP, QOS, CIFS, NFS Ports: LAN/power - RJ-45 Supported Memory Cards: microSD Card, microSDHC Card, microSDXC Card Compliant Standards: CB, IC, UL 60950-1, FCC CFR47 Part 15 B, REACH, IP67, KC, RCM, RoHS 2011/65/EU, BIS, EN 61000-3-3:2013, WEEE 2012/19/EU, EN 61000-3-2:2014, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 55032:2015, LoA, IEEE 802.3af, IS13252-1 (2010)/A1:2013/A2:2015, AS/NZS CISPR 32:2015, EN 50130-4:2011+A1:2014, KN32:2015, KN35:2015, IEC 60529:2013, EN 60950-1:2005+Am1:2009+Am 2:2013, ICES-003 issue 6:2016 Power Requirements: DC 12 V / PoE Class 3 Power Device: 7.6 Watt Shipping Width: 17 cm Shipping Depth: 17 cm Shipping Height: 15 cm Shipping Weight: 1.055 kg Min Operating Temperature: -30 °C Max Operating Temperature: 60 °C Relative Humidity (operating): 0 - 95% (non-condensing)
