JBL Club A5055 5-Channel Amplifier (4x 45W + 1x 500W) The Club A5055 5-channel amplifier delivers a powerful 50 Watts RMS to each of the front and rear speakers in your car. and a whopping 500 Watts RMS to the subwoofer channel - a much smarter subwoofer to full range ratio than what is typical at 5- channel amplifiers. You can also bridge the amplifier to 3-channel mode to deliver 140 Watts RMS to your front speakers while driving your sub at 500 Watts RMS. Speaker-level inputs allow this amplifier to be integrated into almost any system. even one that uses your cars factory radio. Separate high-pass and low-pass crossovers on the front and rear channels allow you to choose the perfect roll-off to best suit speaker placement and cabin acoustics. The subwoofer channel features a low-pass crossover. selectable bass gain and phase switch to optimize subwoofer performance Characteristics
- Compact size
- High and low input level
- Variable crossover and bass boost
- Low noise and distortion
- Input level control
- Full built-in protection
- Phase switch
- RBC wired remote control Technical specifications
- 5 channel car amplifier
- 50 watts RMS x 4 + 320 watts RMS x 1 at
- 4 ohms
- 65 watts RMS x 4+
- 500 watts RMS x 1 at
- 2 ohms
- 140 watts RMS x 2 bridged at 4 ohms +
- 500 watts RMS x 1 at 2 ohms
- Variable high- and low-pass filters (32-320Hz. 12dB / octave) on front and rear channels
- Low-pass filter (32-320Hz. 12dB / octave) on subwoofer channel
- Bass boost on subwoofer channel (0-12dB at 45Hz)
- Phase switch on subwoofer channel (0. 180 degrees)
- Preamp and speaker-level inputs
- Fuse rating: 30A x 34-gauge power and ground leads recommended - wiring and hardware not included with amplifier
- W x H x D = 360mm x 51.3mm x 180mm
- W x H x D = 14-3 / 16 x 2-1 / 16 x 7-1 / 8 Whats in the box?
- One Club A5055 five channel amplifier
- 4 Bare wire-to-RCA adapters
- Six 30A ATO fuses (3 installed. 3 spare)
- Remote bass control module
- 16.5 Remote control cable (RJ-25 plugs on both ends)
- 2 Self-tapping screws for remote (M3 x 15mm)
- 4 Mounting screws (M4 x 53mm)
- Owners ManualTwo JBL stickers1 logo badage Guarantee : 2 years Number of channels: 5 Dimensions: 360 x 51.3 x 180 mm Output: 4 x 45W + 500W
